• Semi-automatic operation
• Heavy duty gear box coupled directly to saw makeup the robust saw head with manual movement on adjustable dual precision linear rails
• Robust sawing head miters 45° left and right, and 60° left
• Infinitely variable blade speed from 15-150 rpm
• Anti-burr clamp with double locking system
• Vertical pneumatic vise • Pneumatic operating vise capable of sliding on dovetail to adjust with saw head mitered position
• Enclosed steel base with chip drawer and coolant tank
• Replaceable blade brush
• Ergonomically positioned control panel includes main disconnect, programmable sawing stroke, saw head feed rate control, and LED display for machine diagnostics • Adjustable material stop with ruler
• Flood coolant with electrical coolant pump
• One blade included (370 x 3 x 32 z=200)
• Foot pedal control with emergency stop
• Second pneumatic horizontal operating vise
• Mist lubrication system
• K40 5’ roller table • “Flip over” material stops with 60” ruler
• R2 ruler extensions for out feed roller tables
• Roller table support stands (extra legs) • Roller table adapter – required if ordering roller table for out feed
• HSS Oxide Coated Blade (370 x 3 x 32)
